Utility Tractor, 55-60HP

Features

The series of tractors feature nice-looking appearance, a spacious cab, adaptability to farm chores, transportation and other heavy-duty tasks;
The naturally aspirated diesel engine produces high horsepower while consuming less fuel;
8F/8R gears enable a wide speed range to suit a variety of needs;
The final transmission applies a compact structural design with a planetary gear reducer and it is load-balanced and durable;
The wet disc brake results in reliable and smooth stop;
The integral front drive axle has a large bearing capacity;
The dual speed PTO meets various farming needs, such as, rotary tillage;
We provide optional air conditioner and high-pressure lifter.

Specifications

Model (with ROPS)	EMF554X	EMF604
Engine type	Naturally aspirated 4-cylinder diesel engine
Rated engine HP (kW)	40.5 (55)	44.1 (60)
Engine speed (rpm)	2200
Clutch	Independent, double action
Gears	8F/8R
Speed range (km/h)	2.74-33.22	2.84-34.54
Brake	Wet, disc
Rear PTO (rpm)	540/1000
Lift capacity (pivot point) (kN)	≥12.8
Hydraulic multiplier (set)	1 or 2
Dimensions (LWH) (mm)	391016152445	418017452570
Wheelbase (mm)	2092	2127
Ground clearance (mm)	360
Min. turning radius (m)	4.5±0.3
Wheel track (F/R) (mm)	1320/1400-1600
Tyre (F/R)	8.3-20/12.4-28	8.3-20/13.6-28
Min. operating mass (kg)	2380	2600
